Description
About This Transmission
The Ford 10R80 is the 10 speed longitudinal automatic transmission that powers the modern F-150, Mustang GT and GT500, Bronco, Raptor, Ranger, Expedition, and Lincoln Navigator. Co-developed by Ford and General Motors starting in 2013 and introduced to the market in 2017 in the F-150 and Mustang GT, the 10R80 replaced the 6R80 6 speed and immediately became the highest gear count automatic ever offered in a Ford pickup or pony car.
The 10 forward gears, wide 7.4 to 1 ratio span, integrated lockup torque converter, and direct acting solenoids deliver smoother acceleration, faster part throttle response, and meaningfully better highway fuel economy than the 6R80 it replaced. The unit is rated for up to 700 lb-ft of stock torque and aftermarket built versions support up to 1,000 horsepower without changing clutch capacity.
The 10R80 is found in the Ford F-150 (2017 onward), F-150 Raptor (2017 onward), Mustang GT (2018 onward), Mustang GT500 (2020 onward), Mustang Mach 1, Bronco (2021 onward), Ranger (2019 onward), Expedition (2018 onward), Lincoln Navigator (2018 onward), and Aviator. It is the universal Ford rear wheel drive automatic of this generation.
Signs You Need a Replacement Transmission
- Torque converter shudder, common on early 2017 to 2019 units (well documented in TSB 19-2155, TSB 20-2331)
- Harsh 1-2 or 2-3 shifts that cannot be calmed by a re flash
- Bind in reverse or delayed engagement after shift to drive
- Ratcheting noise on light throttle, often a sign of internal valve body wear
- Slipping under load (most common after high mileage on towing or modified applications)
- Loss of one or more gears (limp mode)
- Cracked case from impact or off road damage
Known Problems With This Transmission
- Torque converter shudder (2017 to 2019): The most common 10R80 complaint. Caused by internal lockup clutch material that breaks down with age and contaminates the fluid. Ford issued multiple TSBs (most recently TSB 20-2331). Fix is typically a torque converter replacement plus complete fluid flush. We inspect torque converter condition and disclose status on every unit.
- Harsh shift complaints: Early 2017 to 2018 units shipped with calibration that produced harsh 1-2 and 2-3 shifts. Ford released calibration updates. A used unit may need a re flash to current calibration when installed.
- Valve body wear: At very high mileage (150,000 plus) the valve body solenoid pack can develop irregular pressure modulation, causing flare on shifts. We pressure test every unit.
- Pump cavitation on neglected fluid units: 10R80s with overdue fluid service can develop pump cavitation noise. We document fluid condition before shipping.
- Calibration mismatch: A 2017 calibration will not run optimally with a 2022 vehicle and vice versa. We disclose calibration year so your shop knows what to flash.
10R80 Variants by Year and Application
Year matching matters for ECU and TCM calibration:
| Year | Application | Notes |
|---|---|---|
| 2017 to 2018 | F-150 (3.5 EB, 5.0L), Mustang GT, Expedition | Original release. Highest TSB activity. |
| 2019 to 2020 | F-150, Ranger, Mustang, Expedition, Aviator | Updated calibration, improved shift logic. |
| 2020 onward | GT500 (HO calibration), Raptor R, Tremor | Higher torque calibration. |
| 2021 onward | Bronco, F-150 (refresh) | Latest calibration generation. |
| 2024 onward | Mustang Dark Horse, F-150 refresh | Most current spec. |
| Year matching matters for ECU and TCM calibration. We document the exact year and TCM calibration code on every unit so your shop knows what to flash. |
|---|
What Is Included, What Is Not Included
| INCLUDED | Complete transmission case, gear sets, valve body, torque converter, internal harness, output shaft (RWD configuration) or 4WD adapter (4WD configuration). |
|---|---|
| NOT INCLUDED | TCM (Transmission Control Module, often vehicle specific), bell housing if separate, transmission cooler lines, fluid, transfer case (4WD applications), drive shaft. |
| Core Note | No core charge. You are not required to return your old transmission. |
Vehicle Compatibility, Direct Fit
Direct factory applications:
| Ford F-150 | 2017 to present (3.5 EcoBoost, 2.7 EcoBoost, 5.0 Coyote, 3.0 Power Stroke, 3.3 Ti-VCT) |
|---|---|
| Ford F-150 Raptor | 2017 to present (3.5 EcoBoost HO) |
| Ford F-150 Raptor R | 2023 to present (5.2 Predator V8) |
| Ford F-150 Tremor | 2021 to present |
| Ford Mustang GT | 2018 to present (5.0 Coyote) |
| Ford Mustang Mach 1 | 2021 to 2023 (5.0 Coyote) |
| Ford Mustang GT500 | 2020 to 2022 (5.2 Predator) |
| Ford Mustang Dark Horse | 2024 to present |
| Ford Bronco | 2021 to present (2.3 EcoBoost, 2.7 EcoBoost) |
| Ford Bronco Raptor | 2022 to present (3.0 EcoBoost) |
| Ford Ranger | 2019 to present |
| Ford Ranger Raptor | 2024 to present |
| Ford Expedition | 2018 to present |
| Lincoln Navigator | 2018 to present |
| Lincoln Aviator | 2020 to present |
Engine compatibility: 2.3L EcoBoost I4, 2.7L EcoBoost V6, 3.0L Power Stroke V6 Diesel, 3.0L EcoBoost V6, 3.3L Ti-VCT V6, 3.5L EcoBoost V6, 3.5L PowerBoost Hybrid V6, 5.0L Ti-VCT V8 (Coyote), 5.2L Predator V8 (GT500 and Raptor R).
Not sure if this fits? Call (240) 301-0095 with your year, model, and engine. We confirm calibration and RWD vs 4WD configuration before every order ships.
Common Names and Search Terms
| 10R80 | Most common technical search |
|---|---|
| Ford 10 speed transmission | Speed count search |
| F-150 10R80 | Vehicle specific search |
| Mustang 10R80 | Mustang owner search |
| GT500 10R80 | GT500 owner search |
| Raptor 10R80 | Raptor owner search |
| 10R80 4×4 | 4WD configuration search |
| Ford 10 speed auto | Generic Ford 10 speed |
Used OEM vs Rebuilt vs Aftermarket Built
A used OEM 10R80 from a low mileage donor with verified torque converter condition is the most cost effective option for stock or mildly modified F-150, Mustang, Bronco, or Raptor applications. Pricing is roughly one third to one fifth of a built or rebuilt unit. Our 10R80s are pressure tested, shift tested, and the torque converter condition is documented.
A professionally rebuilt 10R80 with updated calibration, upgraded clutch packs, and a new torque converter typically runs $4,500 to $7,500. This is the right path for a high mileage F-150 or for a tow vehicle.
An aftermarket built 10R80 (Project Carbon, PowerTech, Suncoast) is rated for 1,000 horsepower plus and runs $6,500 to $14,000. This is for boosted Coyote, GT500, or Raptor R builds where the stock unit is at the edge of its capacity.
Condition and Inspection Process
- Pressure test on the dyno bench, line pressure recorded across all gears
- Shift test on the dyno bench, all 10 forward gears and reverse cycled
- Torque converter inspected for shudder material, lockup clutch condition disclosed
- Valve body solenoid pack tested for proper actuation
- Internal harness inspected for damage
- Case inspected for cracks, output shaft for runout, splines for wear
- Year and TCM calibration code documented
- Donor vehicle and mileage disclosed where available
Mileage is documented when available from the donor vehicle. Where mileage cannot be confirmed (salvage), we disclose this before shipping.
Buyer Tips, What to Know Before You Order
- Year matching matters: A 2017 unit installed in a 2022 vehicle will need a TCM re flash. Plan for this with your shop.
- Torque converter is the single most common 10R80 failure point. Even on a healthy unit, plan for a complete fluid flush at install. On 2017 to 2019 units, plan for a torque converter replacement as preventive maintenance for towing or hard use.
- RWD vs 4WD: Confirm before ordering. Tail housing and adapter differ.
- Mercon ULV only: Do not substitute. Wrong fluid causes immediate shudder and clutch failure.
- TCM stays with the vehicle: A used 10R80 does not include a TCM. The vehicle TCM controls the new transmission. A re flash is typically required for calibration matching.
Why Buy From Vaz Auto Solutions
- Year and calibration code documented before you pay
- RWD vs 4WD configuration confirmed before shipping
- Torque converter inspected and shudder status disclosed (critical for 2017 to 2019 units)
- Pressure tested and shift tested on the dyno bench, all 10 gears cycled
- Donor vehicle and mileage disclosed where available
- Fitment verified for your specific F-150, Mustang, Bronco, Raptor, Ranger, or Expedition application
- No core charge, keep your old transmission
- Free freight pallet delivery to all 50 states, no hidden fees
- 15 day replacement warranty on internal defects
- Call (240) 301-0095, talk to someone who actually understands 10R80 TSB issues and torque converter shudder
Tom (verified owner) –
Picked up the 10R80 from Vaz Auto Solutions. Smooth shifts, great performance upgrade for my Mustang. Couldn’t be happier.
davis (verified owner) –
Installed the 10R80 in my F-150. It’s like driving a new truck! Vaz Auto Solutions delivered quality and reliability.
Justin O., Tampa FL –
Sourced a 4WD 10R80 from Vaz for a 5.2 Predator swap project. Vaz confirmed the calibration matched my donor harness, output shaft was correct for my driveshaft, and torque converter was healthy. Bench shift test results were sent over before I paid. Install was clean and the transmission has been flawless behind 750 horsepower.
Marcus L., Cleveland OH –
Bought a 10R80 from Vaz to replace mine after the torque converter shudder got bad enough to be unsafe under load. Vaz inspected the converter on the replacement unit and confirmed it was clean. Year matching was 2019, my truck is 2018 so my dealer flashed the TCM at install. Truck shifts smooth as new now. Paid less than half what a rebuilt unit would have cost.
